BenQ PW9520 [ 6000 Ansi Lumens, WXGA ]
BenQ PW9520 [ 6000 Ansi Lumens, WXGA ]
Ultra Flexible Installation
Seven Types of Optional Lenses
To support optimal projector installation and performance in a wide range of environments, seven types of optical lenses ranging from short-throw to long-throw lens are available with glass materials for better focus and large apertures for a brighter image. The lenses are made in Japan to ensure the highest quality.
Motorized Horizontal/Vertical Lens Shift
Lens Shift is a feature often used to overcome projector installation or placement challenges. With the motorized horizontal/vertical lens shift feature, projection adjustments to the projected image can be easily completed with a remote control, whether the projector is placed on a table or mounted in the ceiling.
2D Keystone Correction
When the projector is placed off center, the 2D keystone correction feature gives you a wider projector installation flexibility by correcting the trapezoid effect using horizontal and vertical adjustments.
HDBaseT Advanced Digital Connectivity
Groundbreaking HDBaseT connectivity combines video, audio, and device control signals from multiple sources including PCs, laptops, document cameras, Blu-ray, DVDs and gaming consoles onto a single CAT5 cable, capable of lossless transmissions up to 100 meters. This incredibly efficient and cost-effective connectivity is also ideal for ceiling-mounted and other permanent installations.
360° Rotation-Capable Projection
The projector can be tilted vertically at any angle, allowing projection onto ceilings, walls, floors, or angled signage. The possibilities of impactful visuals in shopping centers, galleries, museums, and theaters are endless.
Ultra Flexible Installation
High Contrast Ratio
The combined expertise of BenQ's projector know-hows delivers an astounding 2800:1 contrast at the highest to significantly improve the black level for superbly rendered image definition.
High Contrast
Low Contrast
(Simulated Photos)
Ultra High Brightness
With ultra high brightness powered by BenQ's unique dual lamp design, presenters are able to present with large-sized projection without losing clarity or the attention of their audience. With two lamps at work, presentations can be carried on with optimal brightness even when one lamp goes out, ensuring sharply detailed, interruption-free presentations under just about any light conditions.
Independent 3D Color Management for Six Primary Colors
BenQ's exclusive 3D color management tool ensures 100% uncompromised color customization with the freedom to independently fine-tune the hue, grain and saturation levels of all six primary colors (R/G/B/C/M/Y).
Interchangeable Color Wheel System
Equipped with BenQ's six-segment color wheel made in collaboration with advanced BrilliantColor™ technology from Texas Instruments, the projectors offers the truest, brightest and liveliest colors. A high-speed, six-segment wheel is available to further boost mid-tone colors to heighten brightness levels for a more life-like picture.
4-segment Color Wheel
(Built in) RGBW
6-segment Color Wheel
(Standard Accessory) RGBYCM
Hassle-Free Maintenance
| Projection System | DLP |
| Native Resolution | WXGA (1280 x 800) |
| Brightness (ANSI Lumens) | 6000 lumens (Dual lamp, Standard lens) |
| Contrast Ratio | 2800:1 |
| Display Color | 1.07 Billion Colors |
| Lens | Wide Fix (5J.JAM37.011) : F=1.85, f=11.6mm Ultra Wide (5J.JAM37.061) : F=1.96~2.3 Wide Zoom (5J.JAM37.021) : F=1.85~2.5, f=18.7~26.5mm Standard (5J.JAM37.001) : F=1.64~1.86, f=26~34mm Semi Long (5J.JAM37.051) : F=1.86~2.48, f=32.9~54.2mm Long Zoom1 (5J.JAM37.031) : F=1.86~2.41, f=52.8~79.1mm Long Zoom2 (5J.JAM37.041) : F=1.85~2.48, f=78.5~121.9mm |
| Aspect Ratio | Native 16:10 (5 aspect ratio selectable) |
| Throw Ratio | Wide Fix (5J.JAM37.011) : 0.8:1(WXGA) Ultra Wide (5J.JAM37.061) : 0.78~0.98:1(WXGA) Wide Zoom (5J.JAM37.021) : 1.31~1.87:1(WXGA) Standard (5J.JAM37.001) : 1.81~2.38:1(WXGA) Semi Long (5J.JAM37.051) : 2.33~3.86:1(WXGA) Long Zoom1 (5J.JAM37.031) : 3.76~5.64:1(WXGA) Long Zoom2 (5J.JAM37.041) : 5.56~8.67:1(WXGA) |
| Image Size (Diagonal) | 80"~500" |
| Zoom Ratio | Wide Fix (5J.JAM37.011) : Fixed Ultra Wide (5J.JAM37.061) : 1.25:1 Wide Zoom (5J.JAM37.021) : 1.4:1 Standard (5J.JAM37.001) : 1.3:1 Semi Long (5J.JAM37.051) : 1.65:1 Long Zoom1 (5J.JAM37.031) : 1.5:1 Long Zoom2 (5J.JAM37.041) : 1.55:1 |
| Lamp Mode (Normal/Economic)* | 2500 / 3000 hours |
| Lens Shift | Wide Fix (5J.JAM37.011) : N/A Ultra Wide (5J.JAM37.061) : 0-45% Vertical; +-10% Horizontal Wide Zoom (5J.JAM37.021) : 0-50% Vertical; +-10% Horizontal Standard (5J.JAM37.001) : 0-50% Vertical; +-10% Horizontal Semi Long (5J.JAM37.051) : 0-50% Vertical; +-10% Horizontal Long Zoom1 (5J.JAM37.031) : 0-50% Vertical; +-10% Horizontal Long Zoom2 (5J.JAM37.041) : 0-50% Vertical; +-10% Horizontal |
| Keystone Adjustment | Horizontal/ Vertical ± 30 degrees |
| Resolution Support | VGA (640 x 480) to WUXGA_RB (1920 x 1200) * RB = Reduced Blanking |
| Horizontal Frequency | 31KHz~92KHz |
| Vertical Scan Rate | 23Hz~85Hz |
| Lamp Wattage | 280W x 2 |
| HDTV Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Video Compatibility | NTSC, PAL, SECAM |
| Weight (Without Packing / With Packing) | 16.5KG (Without lens) |
| Dimensions (W x H x D mm) | 505 x 194 x 385mm |
| Interface | Computer 1 in (D-sub 15pin) x 1 Computer 2 in (5BNC, R/G/B/H/V) x 1 Monitor out (D-sub 15pin) x 1 HDMI 1.4 x 1 (Compatible with HDCP) DVI-D in x 1 (Compatible with HDCP) Component Video in (Y/Pb/Pr) x 1 Composite Video in (RCA) x 1 S-Video in (Mini Din 4 pin) x 1 HDBaseT x 1 (Share with LAN) LAN (RJ45) x 1 (LAN Control) USB (Type Mini B) N/A 12V Trigger x 1 RS232 (DB-9pin) x 1 Wired Remote x 1 IR Receiver x 2 (Front + Rear) |
| Power Consumption | AC 100V, 710W (Standby Power < 0.5W) AC 220-240V, 670W (Standby Power < 0.5W) |
| Audible Noise (Normal/Economic Mode) | 39/ 34/ 35/ 32db (Dual lamp normal/ Dual lamp eco/ Single lamp normal/ Single lamp eco) |
| Power Supply | AC 100V, 7.2A, 50 to 60Hz AC 220-240V, 2.9A, 50 to 60Hz |
| Picture Modes | Presentation/ Standard/ Game |
| On-Screen Display Languages | ENGLISH/ 繁體中文/ FRANÇAIS/ ESPAÑOL/ DEUTSCH/ ITALIANO/ 简体中文/ 한국어/ 日本語/ РУССКИЙ/ Português/ Svenska (12 Languages) |
| Accessories (Standard) | Remote Control without Battery 6 Segments Color Wheel Power Cord (by region) User Manual CD Quick Start Guide Warranty Card (by region) VGA (D-sub 15pin) Cable |
